4. Specification
Model
Spec
Transmitter
Receiver
Input
Input Signal
1 HDMI, 1 IR in
1 IR in, 1 RJ-45
Input Connector
1 HDMI female
1 3.5mm mini jack for IR
in
1 3.5mm mini jack for IR in
1 RJ-45
Video Signal
HDMI1.4
TIA/EIA T568A or T568B
Audio
Digital audio, support
HDMI audio transmitted
through RGB or Y, Cr, Cb
cable.
Digital audio, support HDMI
audio transmitted through
RGB or Y, Cr, Cb cable.
Output
Output
1 RJ-45; 1 IR out
1 HDMI; 1 IR out
Output Connector
1 RJ-45
1 3.5mm mini jack for IR
out
1 HDMI female
1 3.5mm mini jack for IR out
Video signal
TIA/EIA T568A or T568B
HDMI1.4
Transmission Mode
• HDBase-T, synchronous switching mode
General
Resolution Range
480i, 576i, 480p, 576p, 720p, 1080i, 1080p, 3D, 2k-4k
Transmission Distance
Max distance 330 ft. (100m)
Ethernet Transmission Speed
Adaptive 10M/100M, full duplex or half duplex.
Gain
0dB ~ 10dB@100MHz
Differential Phase Error
±10° @ 135MHz_100M
SNR
>70dB@ 100MHz-100M
Bandwidth
10.2Gbps
Return Lost
＜-30dB@5KHz
THD
＜0.005%@1KHz
HDMI Standard
Support HDMI1.4 and HDCP
Min. ～Max. Level
＜0.3V ~ 1.45Vp-p
Impedance
75Ω
Temperature
20 ~ +60 C
Humidity
10% ~ 90%
Power Supply /Consumption
DC 5V power adapter, 6.5W
Chassis Dimension
W3.30" x H1.18" x D5.27
W3.30" x H1.18" x D5.27
Net Weight
1 lb.
1 lb.
