Kantronics KPC-2 - Atai 850 Interface

CONNECT COMPUTER
10
Atari 850 Interface
Looking at socket from outside of Interface
Pin functions of Serial Port No. 1 in 850 Interface Module 9-pin female connector:
Pin Name
TNC DB-25
KPC-4 DB-9
Cable Color
Atari 850
Interface
TXD
RXD
SG
RTS
CTS
2
3
7
4
5
3
2
5
7
8
white
red
orange
green
brown
3
4
5
7
8
