How is this command executed?
Who can execute this
command?
What does this command do?
What is the purpose of this
command?
Click on Test Stop,
or,
press CTRL+E
Stops the margin and burst test.
To abort a test in progress.
Click on Calibrate,
or,
press CTRL+L
Opens the Calibration screen.
(opens the TTU Serial Number
tab in the Configuration
window if a TTU serial number
has not been entered).
To access calibration functions.
Ignore tag type
mismatches for
tags being
calibrated
Click on Calibrate, then,
select the Ignore tag type mismatches
for tags being created check box.
Allows results from one tag
type to be used to calibrate a
different tag type.
To use the calibration
parameters of one tag type to
be used for another tag type.
Click on Calibrate, then,
click on Clear calibration data.
Opens the Password window.
To clear calibration data.
Click on Calibrate, then,
click on Perform margin test.
Opens the Password window.
Starts the calibration margin
test.
