Command
How is this command executed?
Who can execute this
command?
What does this command do?
What is the purpose of this
command?
Change
configuration data
From the T600 Tag Tester
Configuration Tab in the Configuration
window,
click on Change configuration data.
Kapsch service personnel
Opens the Password window.
To allow Kapsch TrafficCom
Canada Inc. personnel to
change the T600 configuration
settings.
Clear
(serial data)
From the Serial Data Dialog window,
click on Clear from the File drop-down
menu.
anyone
Clears the data in the Serial
Data Dialog window.
To discard old serial data so
only the latest serial data is
displayed.
Save PDU data
From the Serial Data Dialog window,
click on Save PDU data from the File
drop-down menu.
anyone
Opens the Save As window.
To save a copy of the PDU data
currently displayed in the Serial
Data Dialog window.
Freeze Screen
From the Serial Data Dialog window,
click on Freeze Screen from the File
drop-down menu.
anyone
Prevents the Serial Data Dialog
window from updating with
new data.
To prevent serial data from
being overwritten so it can be
examined.
