How is this command executed?
Who can execute this
command?
What does this command do?
What is the purpose of this
command?
From the Communication tab in the
Configuration Dialog window,
select the baud rate for the computer
COM port that is connected to the
T600 HOST port from the T600 Comm.
Port drop-down box, then,
click OK.
Establishes the baud rate for
communications between the
customer-supplied computer
and the TTU.
To establish the HOST port
baud rate.
From Communication tab in the
Configuration Dialog window,
select the computer COM port that is
connected to the T600 SCANNER port
from the Scanner Comm. Port drop-
down box, then,
click OK.
Establishes which computer
COM port is connected to the
T600 SCANNER port.
To establish which computer
COM port is connected to the
internal T600 bar code
scanner.
From the TTU Serial Number tab in the
Configuration Dialog window,
enter the TTU serial number (found on
the back of the TTU) in the TTU serial
number box, then,
click OK.
Establishes the TTU serial
number.
To ensure the computer is
connected to the correct TTU.
Also, if multiple calibration files
are installed, to ensure the
correct calibration file is used.
