KAR-TECH MACRO - Page 17

MACRO REMOTE
16
WIRING
PIN
COLOR
DESCRIPTION DTM04-12PA GREY
1
NC
2
NC
3
VIOLET
AIR LATCH CLOSE OUTPUT
4
YELLOW
LOWER DOOR CLOSE OUTPUT
5
BLUE
BELT SPEED PWM OUTPUT
6
WHITE
LOWER DOOR OPEN OUTPUT
7
GRAY
AIR LATCH OPEN OUTPUT
8
ORANGE
UPPER DOOR OPEN OUTPUT
9
GREEN
UPPER DOOR CLOSE OUTPUT
10
RED
POWER (9-30VDC)
11
BLACK
GROUND
12
BROWN
AUX ON/OFF OUTPUT
