Kärcher BR 30/4 C Manual

– 9
Technical specifications
1.783-000.0
1.783-220.0
1.783-223.0 1.783-224.0
Power
Nominal voltage V 220...240
Frequency Hz 1~ 50/60
Average power consumption W 820 750 750
Protective class I
Type of protection IPX4
Vacuuming
Cleaning power, air quantity l/s 26
Cleaning power, negative pressure kPa 13
Cleaning brush
Working width mm 300
Brush diameter mm 60
Brush speed 1/min 1450
Dimensions and weights
Theoretical surface cleaning perfor-
mance
m²/h 200
Fresh/waste water tank volume l 4
Length x width x height mm 390 x 335 x 1180
Transport weight (Adv) kg 12 (12,5)
Total weight (Adv) kg 16 (16,5)
Values determined as per EN 60335-2-72
Hand-arm vibration value m/s
2
<2,5
Uncertainty K m/s
2
0,2
Sound pressure level L
pA
dB(A) 72
Uncertainty K
pA
dB(A) 1
Sound power level L
WA
dB(A) 85
Uncertainty K
WA
dB(A) 1
20 EN

Kärcher BR 30/4 C Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 / 60 Hz
Maximum input power	820 W
Noise level	70.5 dB
Maximum area performance	200 m²/h
Fresh water tank capacity	4 L
Brush rotation speed (min)	1450 RPM
Practical area performance	150 m²/h
Brush contact pressure (min)	100 g/cm²

Weight and Dimensions

Depth	335 mm
Width	390 mm
Height	1180 mm
Weight	11500 g
