Kärcher BR 30/4 C Manual

– 5
Note:
The vacuum bars are attached to the appli-
ance with snaps and can simply be pulled
off.
 Move the suction bar lift pedal to posi-
tion „suction off“ (Fig. 3 - position "1/
ON", see inside front cover).
 Remove the fresh water reservoir.
 Remove the waste water tank.
 Lay the device on the reverse.
 Pull off the vacuum bar downwards.
 Insert the new vacuum bars and lock
them into place.
 Remove the fresh water reservoir.
 Remove the waste water tank.
 Lay the device on the reverse.
 Press the release button for the brush
roller and swivel the brush roller toward
the bottom and pull it off the driver.
 Place the new brush roller on the driver
and lock into place on the opposite side.
In case of danger of frost:
 Empty the fresh and dirt water reser-
voirs.
 Store the appliance in a frost-protected
room.
 DANGER
Risk of injury by inadvertent startup of ap-
pliance and electrical shock.
Prior to all work on the appliance, switch off
the appliance and pull the power plug.
ATTENTION
Risk of damage to the device on account of
water leakage. Empty the waste water tank
and the fresh water tank prior to performing
maintenance tasks on the device.
In case of faults that cannot be remedied
using the table below please contact the
customer service.
Maintenance Works
Replace the vacuum bar.
Replacing the brush roller
Frost protection
Faults
16 EN

Kärcher BR 30/4 C Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 / 60 Hz
Maximum input power	820 W
Noise level	70.5 dB
Maximum area performance	200 m²/h
Fresh water tank capacity	4 L
Brush rotation speed (min)	1450 RPM
Practical area performance	150 m²/h
Brush contact pressure (min)	100 g/cm²

Weight and Dimensions

Depth	335 mm
Width	390 mm
Height	1180 mm
Weight	11500 g
