– 7
Take out the brush roller.
Pull
the water distribution bar out of the
brush tunnel (Fig. 5, see inside front
cover).
Clean the irrigation channel and the
opening in the water distribution bar un-
der running water.
Remove the fresh water reservoir from
the appliance.
Swivel support bow downward and re-
move the waste water tank.
Pull the suction tube connection out to-
ward the rear of the appliance and swiv-
el out both ends of the suction tube (Fig.
6, see inside front cover).
The suction tube is separated and both
ends are accessible for cleaning.
Pull the vacuum bar off toward the bot-
tom, the suction channel in the cleaning
head is accessible for cleaning (Fig. 7,
see inside front cover).
Flush the suction hose and the suction
channel with water or pull or push the
obstruction out with a blunt object.
Clean water distributor Clean suction tube
Accessories
Accessories Description Order number
Roller brush, red Universal brush for all floor coverings. 4.762-428.0
Roller brush, orange Special brush for textured floors such as
safety tiles or grouts
4.762-484.0
Roller brush, white Soft brush for sensitive floors and for pol-
ishing
4.762-452.0
Roller brush, blue Soft brush for deep cleaning of carpets 4.762-499.0
Microfibre roller Cleaning brush made of microfibres with
especially high cleaning performance, es-
pecially for fine stone tiles.
4.762-453.0
Spare suction lip Made of natural rubber. 2 pieces required. 4.777-320.0.
Spare suction lip, oil-re-
sistant
For oil and grease contamination, such as
in a kitchen or workshop. 2 pieces re-
quired.
4.777-324.0
Carpet cleaning kit Deep cleaning of textile surfaces. Consists
of brush rollers, 2 suction bars, 1 l of deter-
gent concentrate, 500 ml stain remover
2.783-005.0
