Kärcher BR 30/4 C Manual

– 1
Please read and comply with
these original instructions prior
to the initial operation of your appliance and
store them for later use or subsequent own-
ers.
Before using the appliance for the first time,
read and observe these operating instruc-
tions and the accompanying brochure:
Safety information for brush cleaning units,
5.956-251.0.
 DANGER
Pointer to immediate danger, which leads
to severe injuries or death.
몇 WARNING
Pointer to a possibly dangerous situation,
which can lead to severe injuries or death.
몇 CAUTION
Pointer to a possibly dangerous situation,
which can lead to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation,
which can lead to property damage.
The scrubbing vacuum cleaner is used for
the wet cleaning of level floors.
A working width of 300 mm and a capacity
of 4 l each of the fresh and dirt water reser-
voirs enable an effective cleaning of small-
er surfaces.
The power supply operation allows a high
capacity without a restriction of the working
time.
Note:
The appliance can be equipped with vari-
ous accessories depending on the cleaning
task.
Please request our catalogue or visit us on
the Internet at www.kaercher.com.
Use this appliance only as directed in these
operating instructions.
– The appliance may only be used for the
cleaning of hard surfaces that are not
sensitive to moisture and polishing op-
erations.
The application temperature ranges
from +5°C to +40°C.
– The appliance is not suited for the
cleaning of frozen grounds (e.g. in cold
stores).
– The appliance may only be equipped
with original accessories and spare
parts.
– The appliance was designed for the
cleaning of floors inside or of covered
surfaces.
– The appliance is not intended for the
cleaning of public traffic routes.
– The appliance is not suited for the use
in potentially explosive environments.
Contents
Safety instructions. . . . . . . . . . EN 1
Function . . . . . . . . . . . . . . . . . EN 1
Proper use . . . . . . . . . . . . . . . EN 1
Environmental protection . . . . EN 2
Control elements. . . . . . . . . . . EN 2
Initial Start-Up . . . . . . . . . . . . . EN 2
Operation . . . . . . . . . . . . . . . . EN 2
Transport. . . . . . . . . . . . . . . . . EN 4
Storage . . . . . . . . . . . . . . . . . . EN 4
Care and maintenance . . . . . . EN 4
Faults . . . . . . . . . . . . . . . . . . . EN 5
Accessories. . . . . . . . . . . . . . . EN 7
Spare parts . . . . . . . . . . . . . . . EN 8
Warranty . . . . . . . . . . . . . . . . . EN 8
EU Declaration of Conformity . EN 8
Technical specifications . . . . . EN 9
Safety instructions
Hazard levels
Function
Proper use
12 EN

Kärcher BR 30/4 C Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 / 60 Hz
Maximum input power	820 W
Noise level	70.5 dB
Maximum area performance	200 m²/h
Fresh water tank capacity	4 L
Brush rotation speed (min)	1450 RPM
Practical area performance	150 m²/h
Brush contact pressure (min)	100 g/cm²

Weight and Dimensions

Depth	335 mm
Width	390 mm
Height	1180 mm
Weight	11500 g
