Karel MS128 Installation & Maintenance Guide
Edition 3.2
13
KN1 – MS128 EX1B Connector
Pin Signal Pin Signal Pin Signal Pin Signal
1(red) LED2 10 SUB5A 19 SUB9A 28 TRK6B
2 SUB1A 11 SUB5B 20 SUB10B 29 TRK6A
3 SUB1B 12 SUB6A 21 SUB10A 30 TRK7B
4 SUB2A 13 SUB6B 22 SUB11B 31 TRK7A
5 SUB2B 14 SUB7A 23 SUB11A 32 TRK8B
6 SUB3A 15 SUB7B 24 SUB12B 33 TRK8A
7 SUB3B 16 SUB8A 25 SUB12A 34 LED1
8 SUB4A 17 SUB8B 26 TRK5B
9 SUB4B 18 SUB9B 27 TRK5A
KN2 – MS128 EX2B Connector
Pin Signal Pin Signal Pin Signal Pin Signal
1(red) LED2 10 SUB5A 19 SUB9A 28 SUB14B
2 SUB1A 11 SUB5B 20 SUB10B 29 SUB14A
3 SUB1B 12 SUB6A 21 SUB10A 30 SUB15B
4 SUB2A 13 SUB6B 22 SUB11B 31 SUB15A
5 SUB2B 14 SUB7A 23 SUB11A 32 SUB16B
6 SUB3A 15 SUB7B 24 SUB12B 33 SUB16A
7 SUB3B 16 SUB8A 25 SUB12A 34 LED1
8 SUB4A 17 SUB8B 26 SUB13B
9 SUB4B 18 SUB9B 27 SUB13A
MS128 EX1B and MS128 EX2B cards are connected to the BPL128 Backplane
through the 64-pin connectors on BPL128 (see Figure A-4). The pin-out of the
MS128 EX1B/EX2B – BPL128 connector is illustrated in the following table :
