The PG100 Local Pager comes with the pager data cable. Like the telephone
data cable of the consoles and feature phones, the pager data cable is formed
up of two parts. One is a cable with a 6-pin RJ plug at both ends and the other
one is a connection box. The connection box has a 6-pin RJ socket at one side
so that one of the free ends of the cable can be fixed to the connection box
easily. The other free end of the cable has also the corresponding RJ socket at
the bottom part of the PG100 cabinet.
The following signals are present on the connection box of pager data cable.
