Installation Instructions – 40649TL
For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 6
Step 4 – Attaching Roof Support
Using a 1/4” x 5/8” flanged bolt and
a 1/4” flanged lock nut and the
previously installed 1/4” x 5/8”
flanged bolt and 1/4” flanged lock
nut, LOOSELY bolt the roof support
to partition.
Step 5 – Installing Handle Mount
Remove handle from slider doorway as shown below.
To Next Page
