Installation Instructions – 40649TL
For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 7
Using a M6 x 25mm hex head, 1/4” lock washer and a 1/4” split lock washer, install handle mount where
handle was previously removed.
Snug tighten.
Step 6 – Installation Preparation
Remove the D-rings from
both the driver’s side and
passenger side “B” pillars.
If wall liner is installed on
driver-side sidewall behind
the driver’s seat, remove wall
liner and wall liner holding
clips nearest the driver’s
seat. Wall liner can be
reinstalled later on during
installation.
