Kasco 3400JF - 3400 J Replacement Parts

20
2
1
4
6
8
15
7
11
14
12
17
13
18
19
16
3
9
5
3400J REPLACEMENT PARTS
10
20
ITEM NO. PART NO. DESCRIPTION Qty
1 92470A151 SCREW, TYPE AB 10
2 334150 CONE, 2400J, 3400J 1
3
334175 INNER CHAMBER, 2400J, 3400J 1
4
344100 INNER HOUSING, 2400J, 3400J 1
5
334300 #6 WASHER 4
6
334125 MAIN HOUSING, 2400J, 3400J 1
7
241005 V TUBE WITH LEGS 1
8
342050 IMPELLER, 3400J 1
9
990275 O RING, CORD 1
10 475643 SHAFT WASHER 2
11 243475 ZINC ASSEMBLY 1
12 990280 SEALING PLUG 1
13 990281 O RING 1
14 990410 DEBRIS FLINGER, .500 DIA. SHAFT 1
15 990600 TOP ASSEMBLY, 2400 3400 1
16 390100 CAN, 3400, 4400 SERIES 1
17 140312 RETAINING CLIP 4
18 840537 LOCK WASHER, 1/4" 4
19 251250 #14 X 1-1/4" LONG HEX WASHER HEAD 4
20 342052 SCREW, 1/2-20 X 1/2, SET 1
3400J Replacement Parts
