KAT KT3 - Set-Up Instructions; Connecting the Drum Module and Pads

SET-UP INSTRUCTIONS
FRONT PANEL
CAUTION!
TO PREVENT ELECTRIC SHOCK AND DAMAGE TO THE DEVICE, MAKE SURE THE POWER IS SWITCHED “OFF” ON
THE DRUM AND ALL RELATED DEVICE BEFORE MAKING ANY CONNECTION.
STANDARD: KICK, SNARE, TOM1-3, CRASH1, RIDE, HIHAT, HIHAT CONTROL PEDAL
EXTENDED: CRASH2, TOM4
Using the provided cable harness, connect with kick, snare, tom1-tom3, ride, crash, hi-hat, hi-hat control triggers. Snare, tom,
crash1, crash2 and ride pads are stereo input and support double triggering; crash 1, crash2, ride cymbal, Hi-hat control pedal
is stereo input.
NOTE:
For details on assembling the drum stand, attaching the digital drum and connecting pads, please refer to the Assembly
Instructions. - Bass drum pedal NOT included on some models.
CRASH1
CRASH2
RIDE
HIHAT
SNARE
DRUM
MODULE
HIHAT PEDAL
KICK
TOM1
TOM2
TOM3
TOM4
