5
SMARTair. SMARTair mobile.
A 3 Technical Data
A 3.1 SMARTair
Measurements:
Width: 450 mm
Depth: 510 mm
Height: 540 mm
Weight: ca. 17,5 kg
Suction capacity: 15-30 L/sec.
max. load for connected unit: 500 W
max. leakage current 0,5 mA
Fuse rating:
mains input 100- 230V T 10A (H) /250 V
fuse ancillary unit
T 4A (L) /250 V stage 1-4
fuse ancillary unit
T 3,15A (L) /250 V stage 2
Ambient conditions:
Suitable for indoor use
Permissible ambient temperature range of
5°C - 40°C
Permissible relative humidity range up to
max. 80 %
Mode of operation
Continuous operation
Degree of soiling: 2
Excess voltage category: II
Protection class: I
Nominal voltage
Check that the mains voltage and frequency
are the same as on the rating plate.
Voltage range: 100/115/230 V 50/60 Hz
Rated power:
Unit consumption max. 1000 W
Disconnection method:
Remove mains plug to disconnect.
Adjustment to national mains voltage:
Set the voltage adjustment switch to
national values (see A 5.1).
