kayse LS30 - MLG30 Sensor Calibration

LS30 CONTROLLER INSTALLATION AND OPERATING GUIDE
22
5.2 Adjustment of Reference Values of LS30 Controller at
MLG30 Level Control Equipments
By zooming the buoy unl it contacts to sensor part (the long
pipe piece that the orange juncon box that cable connecons
are made) assembled next to MLG30 Level Control Equipment,
the reference adjustments will be made.
For entry to reference menu 'Set' and 'Exit' buons are
pressed together unl 'r.lo' parameter is indicated on screen,
While the oat at lowest point 'Set' buon is pressed one
more me,
When 'r.hi' parameter is indicated on screen by taking the
oat to the top point 'set' buon is pressed rapidly and the
main operang screen is returned,
•
•
•
LS30
Level Control Equipment
The oat is moved
to top point
