3
TABLE OF CONTENTS (Continued)
Figure
Page
16 J8 15V / 10V Jumper .................................. .......................................22
17A J17 Analog Signal Input (Voltage Position). .......................................22
17B J17 Analog Signal Input (Current Position) . .......................................22
18 J9 Enable / Inhibit Jumper .......................... .......................................22
19 Typical Hi-Pot Test Setup ........................... .......................................24
20A Forward and Reverse Acceleration Trimpot Position............................26
20B ACCEL Trimpot Adjustment ........................ .......................................26
21 Maximum Speed Trimpot Position .............. .......................................26
22A Forward Current Trimpot Position ............... .......................................27
22B Reverse Current Trimpot Position............... .......................................27
23 IR Compensation Trimpot Position ............. .......................................27
24 Response Trimpot Position ......................... .......................................28
25A Deadband Trimpot Position......................... .......................................28
25B Deadband Trimpot Adjustment ................... .......................................28
26A Offset Trimpot Position................................ ....................................... 29
26B Offset Trimpot Adjustment .......................... .......................................29
27A Scale Trimpot Position ................................ ....................................... 29
27B Scale Trimpot Adjustment ........................... ....................................... 29
