NOTE
The following points must be observed when connecting the device:
- Energy ow direction
- Assignment of measuring voltage input/current transformer input
 Energy ow direction: When mounting the transformer, observe the current ow or
energy ow direction. If the current transformer is mounted the wrong way round, the
measured current will be negative.
Prerequisite is that energy is consumed.
 Assignment - measuring voltage input / current transformer input:
The current transformer on terminal 20/21 (k1/l1) must be arranged in the phase where
the measuring voltage for terminal 10 (L1) is measured.
- The device will display positive current when connection and energy ow direction
are correct.
- If connected incorrectly, the current displayed is negative. Interchange the connec-
tions until the display shows correct values.
CAUTION
Before any interchanging, the current transformer must be shorted out!
