1.5 Disposal
Defective, outdated or disused devices must be properly disposed of.
If required, we are happy to dispose of the devices for you.
1.6 Overvoltage and lightning protection
It is recommended to install overvoltage protection measures to protect our high-quality
devices from damage. We also recommend to protect control voltage inputs and pulse
lines, if required.
2 Connection of the multicomp D6-xxx-7
2.1 Installation and assembly
The applicable DIN / VDE regulations must be observed for installation!
Before the device is connected to the power supply, check whether the local power
supply conditions comply with the specications on the nameplate.
A faulty connection can lead to the destruction of the device! A dierent power fre-
quency inuences the measurement accordingly.
The device must be connected in accordance with the connection chart.
Systems that are at risk from lightning strikes must feature lightning protection for all
input and output lines!
CAUTION
The control voltage as well as the applied measuring voltage of the device must be
protected by means of a back-up fuse.
When connecting the current transformer, the energy ow direction and the correct
assignment to the voltage path must be observed!
During installation, please also observe our notes on safety measures against overvoltage
and lightning in the chapter „Protective measures“ of this manual.
