2.4 Dimensions and Terminals
Product description
X1A Connection for mains voltage, motor, braking resistor and
temperature detection
X2A Connection for control lines
X4A Connection for operator or HSP5 service cable
Connection for shielding / earthing
Pay attention to the input voltage, since 230V and 400V class (3-phase) are possible.
