KEB ACOMBIVERT F5 X3A Original Manual

Installation
18
©
2020 KEB America, Inc.
5.1.2 Mounting
Mount the Brake Transistor Monitor into the F5 elevator drive control cabinet, ensuring
the monitor is mounted an appropriate distance from any other control elements as
shown in the following table.
Mounting Distance Dimension Distance (mm) Distance (inch)
A 150 6
B 50 2
C 30 1.2
D 0 0
X* 50 2
* Distance to preceeding elements in the control
cabinet door
Figure 2: Mounting Dimensions
