do - Parameter
67
ANTRIEBSTECHNIK
Specifies whether the input conditions, which are selected for an output, will be
interconnected with an AND-interconnection (Bit X = 1) or with an OR-interconnection
(Bit X = 0).
Bit - No. Decimal Value Output
0 1 Out 1
1 2 Out 2
Conditions for the output Out 1:
Actual direction of rotation = set direction of rotation and rate of utilization < 80 %
Conditions for the output Out 2:
Rate of utilization > 80 % or actual value <> set value
Settings:
1. Output conditions
do. 1 = 19 (Actual direction of rotation = set direction of rotation)
do. 2 = 12 (rate of utilization > rate of utilization level)
LE. 9 = 80 %
2. Selection of the output conditions
do. 9 (Out 1) = 3 (bit 0 and bit 1 set => cond. 1 and cond. 2 active)
do.10 (Out 2) = 6 (bit 1 and bit 2 set => cond. 2 and cond. 3 active)
3. Logic of the output conditions
do.17 (Out 1) = 2 (bit 1 set => cond. 2 inverted)
do.18 (Out 2) = 4 (bit 2 set => cond. 3 inverted)
4. Interconnection of the output conditions
do.25 = 2 (Bit 0 = 1 => cond. for Out 1 are interconnected AND
Bit 1 = 0 => cond. for Out 2 are interconnected OR)
5. Logic of the digital outputs
do. 0 = 0 (the outputs are not inverted)
Out Condition
Connection (do.25)
Examples of
do. 0 - do. 25
