Annex for Software Version 1.32
86
7 Annex for Software Version 1.32
This Annex is applicable for the software ES.F4.000-B332.
Configuration file No.: 71/72 ( as of COMBIVIS 3.7 )
7.1 Differences to the Standard-Software
The following innovations are integrated in this software:
- Motorpoti function
- Fast-Scan
Operating mode with shorter scan times
- Positioning function
New parameter:
ru.34 Display Motorpoti value
oP.26 Motorpoti function
oP.27 Motorpoti min. value
oP.28 Motorpoti max. value
oP.29 Motorpoti time
ud.12 Fast-Scan-operating mode
EP.05 Positioning
EP.06 Correction factor
EP.07 Shifting factor
EP.08 Set change time lock
Extended parameter:
oP.0 Frequency reference source
di.3/4 Input function
7.1.1 Motorpoti function
The motorpoti function enables a setpoint input via two digital inputs. This function
corresponds with the principle of a mechanic motorpoti.
The display shows the actual status motorpoti of the setpoint value. By writing in
ru.34 the setpoint value between -100% and +100% can be preset with a resolution of
0,01%.
The values 15, 16, 17 are new in oP.0. Unused function numbers have the function
like 0.
The setpoint value preset via motorpoti for the values 15, 16, 17.
Value Function
15 Direction of rotation: digital (oP.3)
16 Direction of rotation: terminal strip
17 Direction of rotation: motorpoti value
Display Motorpoti
value (ru.34)
Frequency reference
source (oP.0)
