Annex for Software Version 1.32
87
ANTRIEBSTECHNIK
The rate of change and the motorpoti function can be adjusted with oP.26. The
motorpoti function is not set programmable. The adjusted value is the sum of the
decimal values.
3210Bit-No.
8421Decimal value (adjust the sum in oP.26)
x x x 0 Motorpoti is programmable in parameter sets; a
change of setpoint is effective in active parameter set
x x x 1 Motorpoti not programmable in parameter sets; a
change of setpoint is effective in all parameter sets
x x 0 x last Motorpoti value is active after power on
x x 1 x Reset of Motorpoti to 0% after power on
00xx
times for the rate of change of the setpoint values
16 sec
0 1 x x 33 sec
1 0 x x 66 sec
1 1 x x Time adjusted with oP.29
oP.27 shows the lower limit of the motorpoti function. The motorpoti min. value is not
set programmable. Data in %.
oP.28 shows the upper limit of the motorpoti function. The motorpoti max. value is not
set programmable. Data in %.
oP.29 shows the time between lower limit and upper limit (oP.27 - oP.28). The
motorpoti time is not set programmable. Data in seconds. Adjustable-setting range
0...300s.
New values:
Value Function
7 increases the value of the motorpoti setpoint value
8 decreases the value of the motorpoti setpoint value
10 sets the motorpoti setpoint value at 0%
Storing of the changed setpoint values in EEPROM (if oP.26, Bit 1 = 0 no Reset after
"Power on") occurs approx. 10 seconds after the last change of the setpoint values.
Adjustment of the motorpoti function:
1. Program one of the free programmable inputs to "increase motorpoti value" (7).
2. Program another one of the free programmable inputs to "decrease motorpoti
value" (8).
3. Set setpoint value source at motorpoti (15-17).
Only by activation of the inputs the setpoint value can be increased/decreased. A
setpoint value decrease always has a higher priority, meaning a simultaneous
activation of incrementing an de-incrementing input the setpoint value is reduced.
Motorpoti funktion
oP.26
Motorpoti min. value
oP.27
Motorpoti max. value
oP.28
Motorpoti time oP.29
Input function
di.3 / di.4
