KEB COMBIVERT F4-S/1.2 User Manual

In - Parameter
74
The inverter type is displayed as a hexal decimal number. Each bit has the following
meaning.
bit 0: Voltage class 0 = 230V
1 = 400V
bit 1-5 Unit size 05,07,09,....
bit 6-9 Control type 0 = 0A.F4 ( F4-C / up to housing E )
1 = 0B.F4 ( F4-S / up to housing E )
2 = 00.F4 ( F4-C / as of housing G )
bit 10-12 Nominal switching freqeuncy 0 = 2kHz
1 = 4kHz
2 = 6kHz
3 = 8kHz
4 = 10kHz
5 = 12kHz
6 = 14kHz
7 = 16kHz
bit 13-15 Maximum switching frequency 0 = 2kHz
1 = 4kHz
2 = 6kHz
3 = 8kHz
4 = 10kHz
5 = 12kHz
6 = 14kHz
7 = 16kHz
Example:
hex 2447
binary 0010010001001110
decimal 11 1 70
=> 07.F4.S 4 / 14kHz / 200V
Display of the rated inverter current in A (resolution 0.1 A).
Display of the maximum possible output frequency in Hz (resolution 0.0125 Hz).
Display of the maximum possible output frequency in kHz (resolution 1 kHz).
The software version number and the control hardware are coded in this parameter.
Position 1: Control hardware (0 = 00.F4, A = 0A.F4, B = OB.F4)
Position 2 + 3: Software version (e.g. 11 = 1.1)
Position 4: Special version (0 = standard)
Inverter Type
(In. 0)
Rated Inverter
Current (In. 1)
Max. Output
Frequency (In. 2)
Max. Carrier
Frequency (In. 3)
Software-Version
(In. 4)
