3
Select Desired Control Mode
Open Loop, V/Hz ASCL Closed Loop
Adjust Speeds, Acceleration, and Deceleration Times
Set Motor Rated Frequency
Set Encoder PPR and Rotation
Direction
1. Startup Procedure
Enter Motor Data
Perform Motor Learn
Set Motor Overload Protection
Set Speeds, Acceleration and Deceleration Times
Startup Complete!
Adjust Speed Control Gains
Adjust Torque Boost
