KEB COMBIVERT S6 User Manual

3.1.4.3 Mounting instructions for control cabinet installation
The following mounting materials with the appropriate quality must be used for mounting
the drive converters.
Required material Tightening torque
Screw assembly ISO 7045 - M6 - 8.8
3.2 Nm
29 lb inch
Table 7: Mounting instructions for control cabinet installation
3.2 Dimensions and weights
3.2.1 Built-in version
16
89
44,5
275 275 308
14
21
170
227
220
Ø 5,8
Ø 5,8
Housing 4
Dimensions All dimensions in mm
Weight
3.2 kg
Figure 1: Dimensions built-in version housing 4
27
DIMENSIONS AND WEIGHTS
