3.3 Unit data
3.3.1 Overview
The technical data are for 2/4-pole standard motors. With other pole numbers the drive
converter must be dimensioned onto the motor rated current. Contact KEB for special or
medium frequency motors.
Unit size 12 13 14
Housing 4
Rated apparent output power S
out / kVA 6.6 8.3 11.4
Max. rated motor power P
mot / kW 4.0 5.5 7.5
Rated output current I
N / A 9.5 12 16.5
Output voltage
U
out / V 0…Uin or 0…Uin_dc/√2
Output phases 3
Output frequency
1)
fout / Hz 0…599
Rated output overload (60 s)
2)
I60s / % 200 150
Rated output overload (3 s)
2)
I3s / % 250 180
Overcurrent
2)
IOC / % 300 216
Rated switching frequency f
SN / kHz 8 4
Rated input current I
IN / A 13 17 21
Rated input voltage U
N / V 400
Input voltage range
U
in / V 184…550
Input voltage range DC
U
in_dc / V 260…750
Mains phases 3
Mains frequency f
N / Hz 50 / 60
Maximum current 0 Hz / 50 Hz at f
S = 8 kHz Imax_out / % 189 / 300 109 / 216 183 / 300
Insulation resistance @ U
_dc = 500 V Riso/MΩ 16.67
Table 8: Overview unit data
1)
The output frequency is to be limited in such a way that it does not exceed 1/10 of the switching
frequency. Units with higher max. output frequency are subject to export restrictions and are only
available on request.
2)
The values refer in % to the rated output current IN.
3.3.2 Rated operation
All rated values refer to a rated operation at UN = 400 V
, rated switching frequency fSN and
an output frequency fout = 50 Hz.
