Display Significance
RX-LED (green) briefly lights up on receipt of a CAN-message.
TX-LED (yellow) briefly lights up on transmission of a CAN-message.
4.5 Ethernet status LEDs
The Ethernet-socket (RJ-45) offers a Link-Status-LED and an Activity-LED.
Display Significance
Link-Status-LED
(green)
Lights up as soon as an Ethernet connection is available.
Activity-LED Lights up when sending and receiving data.
CP 263/S, CP 263/X Displays and operating elements
© KEBA 2014
Project engineering manual V1.01 19
