12 Technical data
12.1 In general
Power supply voltage: 24 V DC
Max. switch-on current: 10 A
Overvoltage category: II
Equipment class: III according to En 61131-2
Max. total power consumption: 95 W
Power consumption own consumption: 40 W
Max. output power K-Bus 24 V: 45 W
Max. output power K-Bus 5 V: 10 W
Fan: Unit fan, replaceable from the outside.
Protection class: IP20
12.2 Environmental conditions
Operating temperature:
+5 °C to +55 °C
Storage temperature: -40 °C to +70 °C
Relative humidity of air: 10 % to 95 % (non condensing)
Vibration resistance: according to EN 61131-2:2007
Shock resistance: according to EN 61131-2:2007
12.3 Computer kernel
Processor:
Embedded Processor - Intel Atom 1,6 GHz
Memory: 1 GB DDR3 SDRAM
Battery-buffered SRAM: 1 MB
12.4 Interfaces
CAN interface (onboard):
1
● Data transmission rate: To be set via software (125 kbit/s to Mbit/s)
● Terminating resistor: YES, can be bridged in plug
● Galvanic isolation: NO
● Connection: DSUB 9-pin pin plug
Ethernet: 3 (choosable 2 EtherCAT)
● Data transmission rate: 10/100 Mbit/s
● Galvanic isolation: Yes, signaling lines
EtherCAT: 2 (choosable 2 Ethernet)
USB:
2
USB 2.0; high speed
CP 263/S, CP 263/X Technical data
© KEBA 2014
Project engineering manual V1.01 39
