4.2 Operation 4.2
BLADES AND BLADE HOLDERS
The Evolution E2 is fitted with an all-new vertical action cutting head which reliably
controls the blade depth and eliminates the need for heavy downward hand pressure
when cutting tough materials such as PVC foamboard. Providing a smooth consistent
cutting action on just about every flexible material used in the Graphics and Sign
making Industries.
The Sabre Cutter bar has been designed to cut a variety of boards to a
thickness of 10mm (3/8") using standard Medium Duty utility blade. Materials to 13mm
(1/2”) can be cut using the GRAPHIK D 017 blade holder.
Consideration should be given to the toughness of the board being cut and the
maximum depth of cut. It is recommended that heavy materials such as PVC foamboard
should ideally be cut using the Graphik blade holder and to a maximum of 6mm (0.25")
whereas, lighter materials like foam centred board can be cut up to the maximum cutting
depth of the blade being used.
