F96VTN and G96VTN: Installation, Start-up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
21
Table 9 – Cooling
4
and Heating Air Delivery - CFM (Bottom Return
5
with Filter)
(SW1-5 and SW2-2 set to OFF, except as indicated. See Notes 1 and 2.)
Unit Size:
0401410
Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1125 1105 1080 1055 1030 1005 975 955 930 905
Cooling (SW2-8,7,6)
OFF OFF ON 605 565 525 485 445 See Note 4
OFF ON OFF 760 730 695 655 625 590 555 525 490 455
OFF ON ON 950 925 900 870 840 810 785 760 730 705
ON OFF OFF 1125 1105 1080 1055 1030 1005 975 955 930 905
ON OFF ON 1130 1105 1080 1055 1030 1005 980 955 930 905
ON ON OFF 1130 1105 1080 1055 1030 1005 980 955 930 905
ON ON ON 1130 1105 1080 1055 1030 1005 980 955 930 905
Maximum Clg Airflow
2
1130 1105 1080 1055 1030 1005 980 955 930 905
CF Switches SW2-5 SW2-4 SW2-3 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Low-Clg Default: OFF OFF OFF 605 565 525 485 445 See Note 4
Low-Cooling (SW2-5,4,3)
OFF OFF ON 605 565 525 485 445 See Note 4
OFF ON OFF 760 730 695 655 625 590 555 525 490 455
OFF ON ON 950 925 900 870 840 810 785 760 730 705
ON OFF OFF 1125 1105 1080 1055 1030 1005 975 955 930 905
ON OFF ON 1130 1105 1080 1055 1030 1005 980 955 930 905
ON ON OFF 1130 1105 1080 1055 1030 1005 980 955 930 905
ON ON ON 1130 1105 1080 1055 1030 1005 980 955 930 905
Cont. Fan Default: OFF OFF OFF 385 335 See Note 4
Continuous Fan (SW2-5,4,3)
OFF OFF ON 245 180 See Note 4
OFF ON OFF 310 245 See Note 4
OFF ON ON 385 335 See Note 4
ON OFF OFF 385 335 See Note 4
ON OFF ON 385 335 See Note 4
ON ON OFF 385 335 See Note 4
ON ON ON 385 335 See Note 4
Heating (SW1)
High Heat Airflow
3
800 770 730 700 665 635 605 570 540 510
Low Heat Airflow
3
560 520 470 425 390 See Note 4
(SW1-5 and SW2-2 set to OFF, except as indicated. See Notes 1 and 2.)
Unit Size:
0601714
Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1330 1295 1260 1220 1190 1150 1110 1075 1045 1005
Cooling (SW2-8,7,6)
OFF OFF ON 725 600 435 280 210 See Note 4
OFF ON OFF 780 725 660 615 540 See Note 4
OFF ON ON 975 925 875 835 785 750 690 655 610 570
ON OFF OFF 1160 1120 1090 1045 1010 970 920 885 840 800
ON OFF ON 1330 1295 1260 1220 1190 1150 1110 1075 1045 1005
ON ON OFF 1705 1650 1595 1545 1475 1415 1340 1275 1200 1105
ON ON ON 1705 1650 1595 1545 1475 1415 1340 1275 1200 1105
Maximum Clg Airflow
2
1705 1650 1595 1545 1475 1415 1340 1275 1200 1105
CF Switches SW2-5 SW2-4 SW2-3 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Low-Clg Default: OFF OFF OFF 725 600 435 280 210 See Note 4
Low-Cooling (SW2-5,4,3)
OFF OFF ON 725 600 435 280 210 See Note 4
OFF ON OFF 780 725 660 615 540 See Note 4
OFF ON ON 975 925 875 835 785 750 690 655 610 570
ON OFF OFF 1160 1120 1090 1045 1010 970 920 885 840 800
ON OFF ON 1330 1295 1260 1220 1190 1150 1110 1075 1045 1005
ON ON OFF 1705 1650 1595 1545 1475 1415 1340 1275 1200 1105
ON ON ON 1705 1650 1595 1545 1475 1415 1340 1275 1200 1105
Cont. Fan Default: OFF OFF OFF 725 600 435 280 210 See Note 4
Continuous Fan (SW2-5,4,3)
OFF OFF ON 725 600 435 280 210 See Note 4
OFF ON OFF 780 725 660 615 540 See Note 4
OFF ON ON 975 925 875 835 785 750 690 655 610 570
ON OFF OFF 975 925 875 835 785 750 690 655 610 570
ON OFF ON 975 925 875 835 785 750 690 655 610 570
ON ON OFF 975 925 875 835 785 750 690 655 610 570
ON ON ON 975 925 875 835 785 750 690 655 610 570
Heating (SW1)
High Heat Airflow
3
1145 1105 1075 1030 995 955 905 870 825 785
Low Heat Airflow
3
870 820 760 720 655 620 560 525 470 435
