(SW1-5 and SW2-2 set to OFF, except as indicated. See Notes 1 and 2.)
Unit Size:
0801716
Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1595 1560 1530 1500 1470 1440 1405 1370 1340 1290
Cooling (SW2-8,7,6)
OFF OFF ON 625 555 495 425 360 300 See Note 4
OFF ON OFF 810 755 700 645 595 540 480 425 380 330
OFF ON ON 1040 995 950 900 860 815 770 725 680 630
ON OFF OFF 1215 1175 1135 1095 1055 1015 975 935 900 860
ON OFF ON 1390 1355 1320 1285 1245 1210 1175 1140 1105 1070
ON ON OFF 1595 1560 1530 1500 1470 1440 1405 1370 1340 1290
ON ON ON 1790 1760 1735 1700 1655 1610 1570 1485 1395 1295
Maximum Clg Airflow
2
1790 1760 1735 1700 1655 1610 1570 1485 1395 1295
CF Switches SW2-5 SW2-4 SW2-3 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Low-Clg Default: OFF OFF OFF 625 555 495 425 360 300 See Note 4
Low-Cooling (SW2-5,4,3)
OFF OFF ON 625 555 495 425 360 300 See Note 4
OFF ON OFF 810 755 700 645 595 540 480 425 380 330
OFF ON ON 1040 995 950 900 860 815 770 725 680 630
ON OFF OFF 1215 1175 1135 1095 1055 1015 975 935 900 860
ON OFF ON 1390 1355 1320 1285 1245 1210 1175 1140 1105 1070
ON ON OFF 1595 1560 1530 1500 1470 1440 1405 1370 1340 1290
ON ON ON 1790 1760 1735 1700 1655 1610 1570 1485 1395 1295
Cont. Fan Default: OFF OFF OFF 625 555 495 425 360 300 See Note 4
Continuous Fan (SW2-5,4,3)
OFF OFF ON 465 390 300 See Note 4
OFF ON OFF 625 555 495 425 360 300 See Note 4
OFF ON ON 690 630 570 510 445 385 See Note 4
ON OFF OFF 690 630 570 510 445 385 See Note 4
ON OFF ON 690 630 570 510 445 385 See Note 4
ON ON OFF 690 630 570 510 445 385 See Note 4
ON ON ON 690 630 570 510 445 385 See Note 4
Heating (SW1)
High Heat Airflow
3
1470 1435 1400 1365 1330 1295 1260 1225 1190 1155
Low Heat Airflow
3
1150 1110 1070 1030 990 950 910 870 830 790
(SW1-5 and SW2-2 set to OFF, except as indicated. See Notes 1 and 2.)
Unit Size:
1002120
Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1890 1845 1800 1755 1700 1655 1610 1560 1510 1460
Cooling (SW2-8,7,6)
OFF OFF ON 1015 825 630 485 405 325 See Note 4
OFF ON OFF 1080 895 815 740 690 615 555 475 See Note 4
OFF ON ON 1155 1080 1020 940 890 825 785 710 660 590
ON OFF OFF 1310 1260 1195 1140 1075 1025 970 925 875 810
ON OFF ON 1520 1475 1425 1365 1315 1255 1210 1155 1110 1055
ON ON OFF 1890 1845 1800 1755 1700 1655 1610 1560 1510 1460
ON ON ON 2290 2230 2160 2085 2005 1915 1820 1730 1640 1525
Maximum Clg Airflow
2
2290 2230 2160 2085 2005 1915 1820 1730 1640 1525
CF Switches SW2-5 SW2-4 SW2-3 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Low-Clg Default: OFF OFF OFF 1015 825 630 485 405 325 See Note 4
Low-Cooling (SW2-5,4,3)
OFF OFF ON 745 640 535 See Note 4
OFF ON OFF 1015 825 630 485 405 325 See Note 4
OFF ON ON 1080 895 815 740 690 615 555 475 See Note 4
ON OFF OFF 1155 1080 1020 940 890 825 785 710 660 590
ON OFF ON 1310 1260 1195 1140 1075 1025 970 925 875 810
ON ON OFF 1520 1475 1425 1365 1315 1255 1210 1155 1110 1055
ON ON ON 1890 1845 1800 1755 1700 1655 1610 1560 1510 1460
Cont. Fan Default: OFF OFF OFF 1015 825 630 485 405 325 See Note 4
Continuous Fan (SW2-5,4,3)
OFF OFF ON 745 640 535 See Note 4
OFF ON OFF 1015 825 630 485 405 325 See Note 4
OFF ON ON 1080 895 815 740 690 615 555 475 See Note 4
ON OFF OFF 1155 1080 1020 940 890 825 785 710 660 590
ON OFF ON 1155 1080 1020 940 890 825 785 710 660 590
ON ON OFF 1155 1080 1020 940 890 825 785 710 660 590
ON ON ON 1155 1080 1020 940 890 825 785 710 660 590
Heating (SW1)
High Heat Airflow
3
1905 1865 1825 1775 1730 1685 1640 1590 1545 1490
Low Heat Airflow
3
1480 1435 1375 1330 1265 1215 1160 1115 1060 1005
Table 9 – Cooling
4
and Heating Air Delivery - CFM (Bottom Return
5
with Filter) (Continued)
