F96VTN and G96VTN: Installation, Start-up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
23
See notes at end of table.
(SW1-5 and SW2-2 set to OFF, except as indicated. See Notes 1 and 2.)
Unit Size:
1002122
Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1990 1945 1905 1865 1820 1780 1735 1695 1650 1600
Cooling (SW2-8,7,6)
OFF OFF ON 885 800 700 See Note 4
OFF ON OFF 1105 1035 955 870 See Note 4
OFF ON ON 1255 1190 1125 1055 975 See Note 4
ON OFF OFF 1445 1390 1330 1270 1210 1140 1075 See Note 4
ON OFF ON 1655 1610 1560 1505 1455 1400 1345 1285 See Note 4
ON ON OFF 1990 1945 1905 1865 1820 1780 1735 1695 1650 1600
ON ON ON 2135 2095 2060 2025 1985 1945 1905 1865 1820 1780
Maximum Clg Airflow
2
2440 2405 2365 2320 2275 2230 2180 2135 2080 2030
CF Switches SW2-5 SW2-4 SW2-3 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Low-Clg Default: OFF OFF OFF 885 800 700 See Note 4
Low-Cooling (SW2-5,4,3)
OFF OFF ON 740 630 See Note 4
OFF ON OFF 885 800 700 See Note 4
OFF ON ON 1105 1035 955 870 See Note 4
ON OFF OFF 1255 1190 1125 1055 975 See Note 4
ON OFF ON 1445 1390 1330 1270 1210 1140 1075 See Note 4
ON ON OFF 1655 1610 1560 1505 1455 1400 1345 1285 See Note 4
ON ON ON 1990 1945 1905 1865 1820 1780 1735 1695 1650 1600
Cont. Fan Default: OFF OFF OFF 885 800 700 See Note 4
Continuous Fan (SW2-5,4,3)
OFF OFF ON 740 630 See Note 4
OFF ON OFF 885 800 700 See Note 4
OFF ON ON 1105 1035 955 870 See Note 4
ON OFF OFF 1255 1190 1125 1055 975 See Note 4
ON OFF ON 1445 1390 1330 1270 1210 1140 1075 See Note 4
ON ON OFF 1655 1610 1560 1505 1455 1400 1345 1285 See Note 4
ON ON ON 1655 1610 1560 1505 1455 1400 1345 1285 See Note 4
Heating (SW1)
High Heat Airflow
3
1810 1765 1720 1675 1625 1575 1525 1475 1425 1375
Low Heat Airflow
3
1405 1350 1290 1225 1160 1100 See Note 4
(SW1-5 and SW2-2 set to OFF, except as indicated. See Notes 1 and 2.)
Unit Size:
1202422
Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 2060 2015 1975 1930 1885 1840 1790 1750 1705 1630
Cooling (SW2-8,7,6)
OFF OFF ON 865 775 690 595 505 425 See Note 4
OFF ON OFF 1080 1005 935 860 785 705 625 555 490 425
OFF ON ON 1285 1220 1150 1085 1020 960 895 820 750 690
ON OFF OFF 1465 1410 1350 1285 1230 1175 1115 1060 1000 935
ON OFF ON 1685 1635 1585 1530 1475 1420 1375 1325 1270 1225
ON ON OFF 2060 2015 1975 1930 1885 1840 1790 1750 1705 1630
ON ON ON 2265 2225 2180 2145 2100 2060 2010 1895 1770 1645
Maximum Clg Airflow
2
2320 2310 2270 2230 2190 2135 2020 1895 1770 1645
CF Switches SW2-5 SW2-4 SW2-3 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Low-Clg Default: OFF OFF OFF 865 775 690 595 505 425 See Note 4
Low-Cooling (SW2-5,4,3)
OFF OFF ON 585 470 See Note 4
OFF ON OFF 865 775 690 595 505 425 See Note 4
OFF ON ON 1080 1005 935 860 785 705 625 555 490 425
ON OFF OFF 1285 1220 1150 1085 1020 960 895 820 750 690
ON OFF ON 1465 1410 1350 1285 1230 1175 1115 1060 1000 935
ON ON OFF 1685 1635 1585 1530 1475 1420 1375 1325 1270 1225
ON ON ON 2060 2015 1975 1930 1885 1840 1790 1750 1705 1630
Cont. Fan Default: OFF OFF OFF 865 775 690 595 505 425 See Note 4
Continuous Fan (SW2-5,4,3)
OFF OFF ON 585 470 See Note 4
OFF ON OFF 730 630 See Note 4
OFF ON ON 865 775 690 595 505 425 See Note 4
ON OFF OFF 865 775 690 595 505 425 See Note 4
ON OFF ON 865 775 690 595 505 425 See Note 4
ON ON OFF 865 775 690 595 505 425 See Note 4
ON ON ON 865 775 690 595 505 425 See Note 4
Heating (SW1)
High Heat Airflow
3
2165 2120 2075 2030 1985 1940 1895 1850 1770 1645
Low Heat Airflow
3
1675 1625 1575 1525 1475 1425 1375 1325 1275 1225
Table 9 – Cooling
4
and Heating Air Delivery - CFM (Bottom Return
5
with Filter) (Continued)
