KeepRite KLP Series - EXPANSION VALVE SELECTIONS; Recommended TXV Selections

K30-KLPD-PDI-4
14/10/20
- 24 -
Medium Temperature Models
Model
KLP
R404A
R507
R407AR407A
R407C
R448AR448A
R449AR449A
SPORLAN SOLENOID VALVES SPORLAN SOLENOID VALVES
104MA-S1D
EBQSE-AA-C 3 EBQVE-AAA-C 3
106MA-S1D
EBQSE-A-C 3 EBQVE-AA-C 3
107MA-S1D
EBQSE-A-C 3 EBQVE-AA-C 3
209MA-S1D
EBQSE-A-C 3 EBQVE-A-C 3
211MA-S1D
EBQSE-B-C 3 EBQVE-A-C 3
214MA-S1D
EBQSE-B-C 5 EBQVE-A-C 3
317MA-S1D
EBQSE-B-C 5 EBQVE-A-C 3
320MA-S1D
EBQSE-B-C 5 EBQVE-B-C 5
422MA-S1D
EBQSE-C-C 6 EBQVE-B-C 5
427MA-S1D
EBQSE-C-C 6 EBQVE-B-C 5
534MA-S1D
EBSSE-6-C 6 EBQVE-C-C 6
640MA-S1D
EBSSE-6-C 6 EBQVE-C-C 6
Above selections based on: 1) 100ºF ( 38ºC ) vapor free liquid entering expansion valve,
2) 110ºF ( 43ºC ) condensing temperature, 3) 9-12ºF ( 4.4-6.7C ) evaporator TD
RECOMMENDED THERMAL EXPANSION VALVE SELECTIONS KLP - LOW PROFILE EVAPORATORS
Low Temperature 6FPI Models
Model
KLP
R404A
R507
R407AR407A
R448AR448A
R449AR449A
SPORLAN SOLENOID VALVES SPORLAN SOLENOID VALVES
104LE-S2D EBQSE-AA-ZP 3 EBQVE-AA-ZP 3
105LE-S2D EBQSE-A-ZP 3 EBQVE-AA-ZP 3
106LE-S2D EBQSE-A-ZP 3 EBQVE-AA-ZP 3
207LE-S2D EBQSE-A-ZP 3 EBQVE-A-ZP 3
209LE-S2D EBQSE-A-ZP 3 EBQVE-A-ZP 3
211LE-S2D EBQSE-B-ZP 3 EBQVE-A-ZP 3
314LE-S2D EBQSE-B-ZP 5 EBQVE-B-ZP 3
316LE-S2D EBQSE-C-ZP 5 EBQVE-B-ZP 5
418LE-S2D EBQSE-C-ZP 5 EBQVE-B-ZP 5
421LE-S2D EBQSE-C-ZP 6 EBQVE-C-ZP 5
526LE-S2D EBSSE-6-ZP 6 EBQVE-C-ZP 5
631LE-S2D EBSSE-6-ZP 6 EBQVE-C-ZP 6
Above selections based on: 1) 100ºF ( 38ºC ) vapor free liquid entering expansion valve,
2) 110ºF ( 43ºC ) condensing temperature, 3) 9-12ºF ( 4.4-6.7C ) evaporator TD
Low Temperature 4FPI Models
Model
KLP
R404A
R507
R407AR407A
R448AR448A
R449AR449A
SPORLAN SOLENOID VALVES SPORLAN SOLENOID VALVES
103VE-S2D EBQSE-AA-ZP 3 EBQVE-AA-ZP 3
104VE-S2D EBQSE-AA-ZP 3 EBQVE-AA-ZP 3
106VE-S2D EBQSE-A-ZP 3 EBQVE-AA-ZP 3
207VE-S2D EBQSE-A-ZP 3 EBQVE-A-ZP 3
208VE-S2D EBQSE-A-ZP 3 EBQVE-A-ZP 3
211VE-S2D EBQSE-A-ZP 3 EBQVE-A-ZP 3
313VE-S2D EBQSE-B-ZP 5 EBQVE-B-ZP 3
316VE-S2D EBQSE-B-ZP 5 EBQVE-B-ZP 3
418VE-S2D EBQSE-C-ZP 5 EBQVE-B-ZP 3
421VE-S2D EBQSE-C-ZP 6 EBQVE-B-ZP 5
524VE-S2D EBSSE-6-ZP 6 EBQVE-C-ZP 5
627VE-S2D EBSSE-6-ZP 6 EBQVE-C-ZP 5
Above selections based on: 1) 100ºF ( 38ºC ) vapor free liquid entering expansion valve,
2) 110ºF ( 43ºC ) condensing temperature, 3) 9-12ºF ( 4.4-6.7C ) evaporator TD
