KeepRite KLP Series - SELECTION DATA; Medium Temperature 6 FPI Selection Data

K30-KLPD-PDI-4
14/10/20
- 3 -
Defrost:
A = Air E = Electric
T = 3 Pipe Hot Gas w/ Electric Heater Pan
H = 3 Pipe Hot Gas w/ Hot Gas Loop Pan
G = Reverse Cycle w/ Electric Heater Pan
R = Reverse Cycle w/ Hot Gas Loop Pan
SELECTION DATA - MEDIUM TEMP. MODELS
Model
KLP
Qty.
Fans
Evaporator Temperature
Selection Capacity BTU/h
Air Flow
Refrig. Charge
R407AR407A
**
20/25°F
(-4/-7°C)
15°F
(-9°C)
10°F
(-12°C)
CFM L/S LB. KG
104M
1
4310 4270 4220 750 350 0.7 0.3
106M 5910 5850 5790 705 330 1.1 0.5
107M
7000 6930 6860 680 320 1.5 0.7
209M
2
8700 8610 8530 1500 710 1.3 0.6
211M 11400 11300 11170 1410 670 1.4 0.6
214M
13700 13600 13430 1360 640 2.0 0.9
317M
3
16900 16700 16560 2115 1000 3.0 1.4
320M
20300 20100 19890 2040 960 4.0 1.8
422M
4
22400 22200 21950 2820 1330 3.3 1.5
427M
27000 26700 26460 2720 1280 3.9 1.8
534M 5 33700 33400 33030 3400 1600 6.5 2.9
640M 6 40400 40000 39590 4080 1930 7.8 3.5
- Capacities at other TD within a range of 8 to 15 °F (4.4 to 8.3°C) are directly proportional to TD, or use formula:
Capacity = Rated capacity ÷ 10 x TD.
** For R448A/R449A, use conversion factor 0.96
R407AR407A
R407C
R448AR448A
R449AR449A
Medium Temperature - 6 FPI Models
KLP - LOW PROFILE EVAPORATORS
Model
KLP
Qty.
Fans
Evaporator Temperature
Selection Capacity BTU/h
Air Flow
Refrig. Charge
R404A
R507
20/25°F
(-4/-7°C)
15°F
(-9°C)
10°F
(-12°C)
CFM L/S LB. KG
104M
1
4200 4160 4120 750 350 0.6 0.3
106M 5770 5710 5650 705 330 1.0 0.5
107M
6830 6760 6690 680 320 1.4 0.6
209M
2
8500 8420 8330 1500 710 1.2 0.5
211M 11100 10990 10880 1410 670 1.3 0.6
214M
13300 13200 13030 1360 640 1.8 0.8
317M
3
16600 16400 16270 2115 1000 2.8 1.3
320M
19800 19600 19400 2040 960 3.7 1.7
422M
4
21800 21600 21360 2820 1330 3.0 1.4
427M
26400 26100 25870 2720 1280 3.6 1.6
534M 5 32900 32600 32240 3400 1600 6.0 2.7
640M 6 39400 39000 38610 4080 1930 7.2 3.3
Theabovecapacitieswereratedbasedonnominal10℉TD
Capacities at other TD within a range of 8 to 15 °F (4.4 to 8.3°C) are directly proportional to TD, or use formula:
Capacity = Rated capacity ÷ 10 x TD.
R404A
R507
Medium Temperature - 6 FPI Models
