ECLIPSE – INSTALLATION/OPERATION MANUAL
Eclipse Jan-10
14
6.0 GENERAL SPECIFICATIONS
CLEARANCE TO COMBUSTIBLES
Top 1” (25 mm)
Front 24” (610 mm)
Rear 24” (610 mm)
Side – Non Access 2” (51 mm)
Side – Access 24” (610 mm)
Flue Pipe 9” (229 mm)
Floor Non-combustible
DRAFT PRESSURE
Breech draft pressure -0.04” wc
Overfire draft pressure -0.01” wc
(Not Applicable to Direct Vent Units)
BURNER INSERTION (overall)
Riello 40F3 & BF3 - Beckett PA402 & 404 2 1/2” (63 mm)
AIR/BLOWER DATA
External static – Non A/C 0.2” wc
External static – A/C 0.5” wc
Cooling 3 tons
Maximum air temperature rise 85°F
High Limit, max design outlet temp 200°F
Thermostat anticipator 0.2 amps (Classic Air)
0.1 amps (EVO)
1/3 hp #1 speed @ 0.50 in. wc static pressure 1200 CFM (Classic Air & EVO)
1/2 hp @ 0.50 in. wc static pressure 1200 CFM (MAX)
MOTOR/BLOWER
Classic Air 1/3 hp 4 Speed/GT 10 DD
EVO 1/3 hp 4 Speed/GT 10 DD
MAX 1/2 hp ECM/GT10 DD
FAN/HIGH LIMIT CONTROL
Classic Air Fan and Limit Control
EVO EVO Control Board (Variable or Non-Variable)
MAX MAX Control Board (Variable)
FAN CENTRE RELAY – Classic Air models only
Honeywell R8285A1048
White Rodgers 8A05A-101
DIMENSIONS
Depth 46 7/8” (1191 mm)
Height 29 3/8” (746 mm)
Width 19 3/8” (492 mm)
