ECLIPSE – INSTALLATION/OPERATION MANUAL
Eclipse Jan-10
15
PLENUM DIMENSIONS
Cold air return 18 x 20 3/4” (457 x 527 mm)
Hot air supply 18 x 21 3/4” (457 x 552 mm)
Plenum spacing 1 3/8” (35 mm)
A/C COIL LOCATION
Minimum height above the heat exchanger 10” (254 mm)
See A/C Coil Manufactures Requirements
OPENING HEIGHTS – from base
Burner c/l 10” (254 mm)
Smoke pipe c/l 22 1/2” (572 mm)
SMOKE/VENT PIPE
5” Chimney
4” Direct Vent
CLEANOUTS
Front Covers & Burner Opening
AIR FILTERS 16” x 20” x 1”
THERMOSTAT
Classic Air Any thermostat
EVO Any thermostat
MAX Any thermostat
FUEL
Not heavier than No. 2 furnace oil.
ELECTRICAL – 120 Volts, 60 Hz
Canada Less than 12 amps.
USA 13.3 amps, circuit protection 20 amps.
7.0 CLASSIC AIR COMFORT ADJUSTMENTS
o Outlet air is initially too warm or too cold - adjust the fan on setting.
o Outlet air consistently too warm or too cold - change the blower motor speed to give the
specified air temperature rise (70 - 85°F).
o Blower motor shuts off and the oil burner keeps going - the “FAN ON” setting is set too
low or the inlet air is below 50°F.
o Outlet air gets too warm and burner shuts down - increase air by changing the blower
motor speed to give the specified temperature rise (70 - 85°F).
o Outlet air is too cold or too warm at the end of the heating cycle after the burner has
turned off - adjust the “FAN OFF” time higher or lower.
