Keithley 2281S Series User Manual

Home screen for the battery test function
The above gure shows the home screen for the battery test
function.
You can enter this screen by choosing the battery test
function on the startup screen.
The top row on the Home screen displays the status and
event indicators. You can select these options to open dialog
boxes that provide additional information about the status or
event.
The OUTPUT view area of the Home screen displays the
values of the battery under test.
The soft-key area is on the bottom of the Home screen. It
shows the present setting values. You can change these
values by pressing the buttons below the screen. Select
Next to view additional soft-key area options.
