Series 3700A System Switch/Multimeter Reference Manual Section 3: Instrument description
3700AS-901-01 Rev. D/June 2018 3-3
Series 3700A display during operation
Active channel (slot 1, channel 004).
Channel state (open, 2-pole operation).
Present state of the DMM attributes for displayed channel:
▪ The 4-WΩ and autorange are enabled
â–ª Dry-circuit ohms is disabled (DRY-)
â–ª Offset compensation is off (OC-)
For detailed descriptions of the DMM attribute symbols, see the table labeled
"DMM attribute symbols" below.
Arrow indicating that more menu items exist; turn the navigation wheel to
the left or right to see the additional items.
The 4-WΩ and autorange are enabled.
Indicates the instrument is being controlled remotely. Press the LOCAL
(EXIT) key to control the instrument through the front panel.
The table below lists the display indicators and what they mean.
Measure autorange is selected
Instrument is in the editing mode
Questionable reading or invalid calibration step
Digital filter is enabled
Instrument is addressed to listen
Enabled for mX+b, percent, or reciprocal (1/X) calculation
Instrument is in remote mode
Service request is asserted
Instrument is addressed to talk
Instrument is processing a front-panel reading request
Four-wire resistance or RTD temperature reading
Readings are being stored in the buffer
