Keithley 3700 Series User Manual

Appendix B: Verification and adjustment Series 3700A System Switch/Multimeter Reference Manual
B-8 3700AS-901-01 Rev. D/June 2018
ACV verification data
Use the following values to verify the performance of the Series 3700A. Actual values depend on
published specifications (see Example reading limit calculation (on page B-3)).
Connect to the Fluke 5700A calibrator
Description
Range (V)
Test point (V)
Lower limit (V)
Upper limit (V)
Verify ACV 100 mV at 20 Hz
1.00E-01
1.00E-01
9.897000E-02
1.010300E-01
Verify ACV 100 mV at 1 kHz
1.00E-01
1.00E-01
9.992000E-02
1.000800E-01
Verify ACV 100 mV at 50 kHz
1.00E-01
1.00E-01
9.984000E-02
1.001600E-01
Verify ACV 100 mV at 100
kHz
1.00E-01
1.00E-01
9.932000E-02
1.006800E-01
Verify ACV 1 V at 20 Hz
1.00E+00
1.00E+00
9.992000E-01
1.000800E+00
Verify ACV 1 V at 1 kHz
1.00E+00
1.00E+00
9.992000E-01
1.000800E+00
Verify ACV 1 V at 50 kHz
1.00E+00
1.00E+00
9.984000E-01
1.001600E+00
Verify ACV 1 V at 100 kHz
1.00E+00
1.00E+00
9.932000E-01
1.006800E+00
Verify ACV 10 V at 1 kHz
1.00E+01
1.00E+01
9.992000E+00
1.000800E+01
Verify ACV 10 V at 50 kHz
1.00E+01
1.00E+01
9.984000E+00
1.001600E+01
Verify ACV 10 V at 100 kHz
1.00E+01
1.00E+01
9.932000E+00
1.006800E+01
Verify ACV 100 V at 1 kHz
1.00E+02
1.00E+02
9.992000E+01
1.000800E+02
Verify ACV 100 V at 50 kHz
1.00E+02
1.00E+02
9.984000E+01
1.001600E+02
Verify ACV 100 V at 100 kHz
1.00E+02
1.00E+02
9.932000E+01
1.006800E+02
Verify ACV 300 V at 1 kHz
3.00E+02
3.00E+02
2.997600E+02
3.002400E+02
Verify ACV 300 V at 50 kHz
3.00E+02
3.00E+02
2.995200E+02
3.004800E+02
Connect to the Fluke 5725A amplifier
Description
Range (V)
Test point (V)
Lower limit (V)
Upper limit (V)
Verify ACV 300 V at 100 kHz
3.00E+02
3.00E+02
2.979600E+02
3.020400E+02
