Reset the scan list
You can clear the scan list and return scan settings to their factory defaults using scan reset. A scan
reset does not affect any settings in the instrument except the scan list and trigger model.
The settings that are affected are:
• Channels and patterns are removed from the scan list
• Bypass: Returned to default setting of ON
• Mode: Returned to default setting of Open All
• Scan count: Returned to default setting of 1
• Trigger to start scan: Set to Immediate
• Trigger to continue channel action for each scan step: Setting is cleared
• Arm (Scan Start Stimulus) is set to None
• Channel Action Stimulus is set to Channel Ready Event
• Channel Ready Event is set to None
• Scan Complete Even is set to None
To reset the scan list from the web interface:
1. From the left navigation of the web interface Home page, select Scan Builder.
2. Click Scan & Trigger Reset.
Run the scan
You can run a scan in one of several ways:
• Background: Runs the scan in the background so that you can perform other tasks while the
scan is running. You can use the Query State to check scan status.
• Step by Step: Steps through the scan.
To run the scan as a background scan from the web interface:
Click Execute Background or Step by Step.
Stop the scan
To stop the scan from the web interface:
On the Build & Run tab, click Abort.
Monitor the state of the scan
To monitor the state of the scan, you can click Query State on the Build & Run tab. Query State
displays the current state of the scan, which can be:
• Empty: No scan defined
• Building: Scan list is being created
• Running: Scan in process
• Success: Scan completed successfully
