Series 3700 Screw Terminal Installation Instructions
6 PA-955 Rev. E / April 2010
Figure 6: Model 3732-ST-R screw terminal assembly
NOTE The Model 3732-ST-R screw terminal assembly is labeled to show the correct
connections for the dual 8x28 configuration. Insertable overlays are provided
with the screw terminal assembly that show the correct wiring for the single
16x28 and single 8x28 (2-pole) configurations.
For additional information about using the Model 3732 card and available
accessories, refer to the Model 3732 Quad 4x28 Reed Relay Matrix Card
Connection Information (part number PA-1021) document that came with your
Model 3732 card. You can also download the document from
www.keithley.com
.
