2-26 TSP Programming Fundamentals Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 2 topics
Script storage is set from the Script Attributes tab of the Run window and is shown
in
Figure 2-14. In the Script Attributes tab, click Volatile or Non-volatile. After
selecting non-volatile memory, Auto Run can be enabled (√) to automatically run
the script whenever the SourceMeter is turned on.
Debug - Click Generate Debug File to generate a read-only copy of the script. A
folder named “Debug” and the debug file (.DBG) is added to the project.
After changing the storage configuration, click Apply.
Figure 2-14
Run dialog box (Script Attributes tab)
Launching a script
After checking and/or changing a launch configuration, the script is launched from
the Run dialog box by clicking the Run button shown in
Figure 2-13.
A script can be re-launched directly from the toolbar located at the top of the Test
Script Builder.
Figure 2-15 explains how to re-launch a script from the toolbar.
Figure 2-15
Re-launching a script from the Test Script Builder toolbar
Click Run and click
Run Last Launched
in the drop-down menu.
OR
Click and then click the
script in the drop-down
menu.
Click
OR
To Next Page
