Kelly KHS Series User Manual

Kelly KHS High Voltage Sinusoidal Brushless Permanent Magnet Motor Controller User’s Manual V 1.25
41
3,1
¤¤¤ ¤
Reserved
3,2
¤¤¤ ¤¤
Internal reset
May be caused by some transient fault condition like
a temporary over
-current, momentarily high or low
battery voltage. This can happen during normal
operatio
n.
3,3
¤¤¤ ¤¤¤
Hall throttle is open
or short-circuit
When the throttle is repaired, a restart will clear the
fault.
3,4
¤¤¤ ¤¤¤¤
Angle sensor error
1.Speed sensor
type error，customers may set the
correct sensor type through user program or App.
Please download how to use Identification function
instruction from our website.
2.
Incorrect wiring.
3.
Speed sensor is damaged or defective. Or
feedback signal is erratic.
4,1
¤¤¤¤ ¤
Reserved
4, 2
¤¤¤¤ ¤¤
Reserved
4, 3
¤¤¤¤ ¤¤¤
Motor
over
-temperature
Motor temperature
is higher than the configured
maximum. The controller will shut down until the
motor temperature cools down.
4, 4
¤¤¤¤ ¤¤¤¤
Hall Galvanometer
sensor
error
1. Hall galvanometer device is damaged inside the
controller.
This error code is only valid for
KHS-N
/IPS controller.
Customers may read error codes in PC software or Android Tablet
Contact Us:
Kelly Controls
Home Page:
https://kellycontroller.com/
Download user manual,instructions and user program:
https://kellycontroller.com/support/
E-mail:
Sales@Kelly-Controls.com
Phone:
(01) 224 637 5092
