6. TECHNICAL DATA
Loading capacity
DC-
Electrode
sizes to be
used
Voltage
class
Cooling Connection to TIG-unit
Gas/
current
Water/
current
Water Gas
40% ED 100% ED
TTK 130
130A
-
ø 1,0 – 2,4 L Air R¼ - - -
TTK 130F
130A
-
ø 1,0 – 2,4 L Air R¼ - - -
TTK 160
160A
-
ø 1,0 – 2,4 L Air R¼ - - -
TTK 160S
160A
-
ø 1,0 – 2,4 L Air R¼ - - -
TTK 220
220A
-
ø 1,0 – 3,2 L Air R¼ - - -
TTK 220S
220A
-
ø 1,0 – 3,2 L Air R¼ - - -
TTK 300W
300A 200A ø 1,0 – 2,4 L Liquid
- min. 1 l/min
In inlet:
- max. 50 °C
- min. 1 bar
- max. 5 bar
- R3/8 R3/8 R1/4
TTK 350W
350A 250A ø 1,0 – 4,0 L Liquid
- min. 1 l/min
In inlet:
- max. 50 °C
- min. 1 bar
- max. 5 bar
- R3/8 R3/8 R1/4
TTK
250WS
250A 200A ø 1,0 – 4,0 L Liquid
- min. 1 l/min
In inlet:
- max. 50 °C
- min. 1 bar
- max. 5 bar
- R3/8 R3/8 R1/4
Make sure that the torch being in your use is designed for max. welding current needed by
you.
The torch meets the construction and safety requirements according to norm
IEC / EN 60974-7.
9
TTK / © Kemppi Oy / 1130
