MSD 1-meter unit layout
22
X1
R4
R6R5R3
X4
X3
R3 Set current minimi (no function with Kempomig-power sources)
R4 Set current maximum (no function with Kempomig-power sources)
R5 Voltage display
R6 Current display
X3 (no function with Kempomig-power source)
X4 (no function with Kempomig-power sources)
