Net voltage operational limits
Mastertig 2000 Minimum Maximum
230 Vac 165 Vac 270 Vac
Mastertig 2500 Minimum Maximum
230 Vac 175 Vac 270 Vac
400 Vac 300 Vac 460 Vac
460 Vac 340 Vac 530 Vac
Mastertig 3500 Minimum Maximum
400 Vac 365 Vac 460 Vac
Signals between control card A001 (panel) and A002, X1 and X2
No remote controller
Remote controller minimum Remote controller maximum
Set value from remote controller, voltage on connector X1/2
38
